The KAK 4-Way Reversing Valve is a critical directional control component in HVAC and heat pump systems, enabling smooth refrigerant flow switching between heating and cooling cycles.
Built from durable brass and copper, this reversing valve offers long service life and high reliability under R22, R410A, R32, R407C, R452A, and R454A refrigerants. Integrated solenoid coil design ensures fast and stable switching performance.
Key Features
- 4-way structure for efficient flow control
- Integrated solenoid coil with optional contactors
- Compatible with major brands (Goodman, Carrier, LG)
- Wide capacity range for residential and commercial heat pumps
- OEM customization available (coil voltage 12V/24V/220V)
Applications
- Heat pump reversing systems
- Chillers and VRF/VRV units
- Air conditioning systems with reversible flow
- OEM and replacement applications
Size Chart – KAK 4-Way Reversing Valves with Solenoid Coils
| Model No. | Connection Size (inch) | Applicable Capacity (HP) | Applicable Refrigerants | Coil Voltage | Dimensions L×W×H (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| KAK-RV-4.0 | 1/4” × 1/4” × 3/8” × 3/8” | 1–1.5 HP | R22 / R410A / R407C / R134a | AC 220V / 50-60Hz | 110 × 70 × 55 | 0.35 |
| KAK-RV-7.0 | 3/8” × 3/8” × 1/2” × 1/2” | 1.5–2.5 HP | R22 / R410A / R407C / R134a | AC 220V / 110V | 125 × 75 × 60 | 0.45 |
| KAK-RV-12.0 | 1/2” × 1/2” × 5/8” × 5/8” | 2–3.5 HP | R22 / R410A / R407C / R134a | AC 220V / 110V | 135 × 80 × 65 | 0.55 |
| KAK-RV-20.0 | 5/8” × 5/8” × 3/4” × 3/4” | 3–5 HP | R22 / R410A / R407C / R134a | AC 220V / 110V | 150 × 95 × 75 | 0.75 |
| KAK-RV-32.0 | 3/4” × 3/4” × 7/8” × 7/8” | 5–8 HP | R22 / R410A / R407C / R134a | AC 220V / 110V | 165 × 110 × 85 | 1.05 |
| KAK-RV-50.0 | 7/8” × 7/8” × 1-1/8” × 1-1/8” | 8–12 HP | R22 / R410A / R407C / R134a | AC 220V / 110V | 185 × 125 × 95 | 1.45 |
| KAK-RV-80.0 | 1-1/8” × 1-1/8” × 1-3/8” × 1-3/8” | 12–20 HP | R22 / R410A / R407C / R134a | AC 220V / 110V | 220 × 140 × 110 | 2.10 |
The above data are for general reference only. Different connection sizes, capacities, and coil voltages can be customized according to customer requirements.
FAQ– Reversing Valve for Heat Pump
Q1: What is a 4-way reversing valve in HVAC systems?
A: It’s a directional control valve that switches refrigerant flow between heating and cooling cycles in a heat pump. The 4-way design allows efficient flow reversal with minimal pressure loss.
Q2: What does a reversing valve do in a heat pump?
A: The reversing valve allows a heat pump to reverse the refrigerant direction, turning the system from cooling to heating mode or vice versa.
Q3: How much does heat pump reversing valve replacement cost?
A: Replacement cost varies by model and capacity, typically ranging from $100–$400 for standard residential units. KAK provides OEM and replacement valves for all major brands.
Q4: Do you offer solenoid coils with reversing valves?
A: Yes, KAK supplies reversing valves with integrated or separate solenoid coils and contactors for OEM heat pump applications.
Q5: Are KAK valves compatible with Goodman or Carrier systems?
A: Yes, our valves are compatible with most HVAC and heat pump brands, including Goodman, Carrier, LG, and Gree units.
